The mechanical walking structure adopts imported linear guide rails, precision worm gear reducers, and stepper motor drives. The whole machine features small transmission clearance, high rigidity, and stable, reliable operation, making it highly convenient for integration.
🔄
The unique middle through-hole design of the HBT-3 welding positioner is specifically adapted for overlaying welding operations on inner and outer circles of various super-long shaft parts. A servo motor drives the slewing bearing to achieve precision transmission of the spindle with small clearance and high rotation accuracy.
📦
Integrated structure ensures the equipment is easy to transport and move, facilitating flexible workspace management.
🖥️
Featuring CNC and PLC dual system integration with five-axis linkage, the machine can complete welding actions for taper arc cylindrical products in a single operation.
🛡️
Equipped with integrated lighting, an exhaust fan, and a shading mobile protective door. The design is humanized, featuring simple operation and a beautiful overall structure.
🛠️
Ideally suited for surfacing and repairing the wear-resistant layers of general shaft parts and pipe parts. It is also highly effective for surfacing and repairing disc parts.
Frequently Asked Questions (FAQ)
What types of parts can this welding machine repair?
This equipment is specifically designed for surfacing and repairing the wear-resistant layers of general shaft parts, pipe parts, and disc parts.
What are the advantages of the HBT-3 welding positioner?
It features a unique middle through-hole design that allows for overlaying welding on inner and outer circles of super-long shaft parts, supported by a high-precision servo-driven spindle.
Does the machine support complex shapes?
Yes, with CNC and PLC dual system integration and five-axis linkage, it can complete welding for taper arc and cylindrical products in one cycle.
What control system drives the equipment?
The machine utilizes a high-reliability Mitsubishi FX series PLC combined with a 7-inch Wellington touch screen for precise control.
Is the machine safe and user-friendly for operators?
Absolutely. It includes integrated lighting, an exhaust fan for fumes, and a shading mobile protective door to ensure a safe and comfortable working environment.
What is the loading capacity of the positioner?
The HBT-3S welding positioner is rated for a load of 300 kg, providing stability for heavy industrial components.
